hlwgpu

hlwgpu packages the shared xgpu API for Haxe programs on Ash and HashLink. Native programs call xgpu.hdll, which uses Rust and wgpu. Browser programs load the supplied xgpu.wasm side module and WebGPU agent through their runtime's Wasm harness.

Install

Download the archive for your platform from GitHub Releases, unpack it, and register that directory as the hlwgpu haxelib. Keep xgpu.hdll beside your HashLink bytecode or executable.

haxelib dev hlwgpu /path/to/unpacked/hlwgpu

Add -lib hlwgpu to your Haxe build. The archive already contains the generated API, so application developers do not need Rust, WebIDL tooling, or xgpu's generator.

The generated API uses ash.Future<T> for asynchronous results. Ash provides the matching runtime ABI. A different HashLink host can use the same hdll when it provides the Ash Future ABI described by the ash-future package.

First device

import gpu.GpuInstance;
import gpu.Power;

var instance = new GpuInstance();
var adapter = instance.requestAdapter(Power.HighPerformance).await();
var device = adapter.requestDevice().await();
trace('${adapter.name()} through ${adapter.backend()}');

GPU work that completes later returns ash.Future<T>. await() parks an Ash fiber; then() attaches a continuation. GPU resources expose destroy() so applications can release driver memory at a predictable point.

The haxelib exposes two namespaces:

• gpu is xgpu's generated portable WebGPU API plus native extensions.
• hlwgpu.hxsl compiles typed HXSL shaders to WGSL during Haxe compilation.

Use the official WebGPU specification as the reference for portable behavior. Native-only capabilities such as backend selection, pipeline caches, mesh shaders, ray tracing, and passthrough shaders are described by their generated classes and are available only where the selected wgpu backend supports them.

Typed shaders

Implement hlwgpu.hxsl.Shader and put the shader expression in SRC. The macro checks it during Haxe compilation and emits WGSL plus its resource and pipeline layout constants.

class TriangleShader implements hlwgpu.hxsl.Shader {
	static var SRC = {
		@input var input:{position:Vec2};
		var output:{position:Vec4, color:Vec4};
		@param var tint:Vec4;

		function vertex() {
			output.position = vec4(input.position, 0, 1);
		}

		function fragment() {
			output.color = tint;
		}
	};
}

var shader = device.createShader(TriangleShader.WGSL);

TriangleShader.WGSL contains the generated shader. The macro also emits uniform offsets, bind groups, bindings, vertex locations, render targets, and pipeline constant keys as static fields.

Releases

Archive	Intended use
hlwgpu.zip	Haxelib package with every desktop xgpu.hdll, staged beside the .hl at compile time
xgpu-<platform>.hdll	One desktop xgpu.hdll, as packaged in the Haxelib ZIP
hlwgpu-hdll-<platform>	Desktop xgpu.hdll, generated Haxe API, and haxelib manifest
hlwgpu-ios-* / hlwgpu-android-*	Static native archive for a mobile runtime integration
hlwgpu-wasm-ash	xgpu.wasm, runtime-neutral loader entry, and Ash browser agent modules
hlwgpu-haxe	Generated Haxe API without a platform binary

Native backends are Metal on Apple platforms, D3D12 on Windows, and Vulkan on Linux. The dedicated Windows Vulkan archive enables Vulkan as another runtime choice; from the Haxelib package, -D hlwgpu_vulkan stages it. Android builds include Vulkan and OpenGL ES. Browser Wasm uses the browser's WebGPU implementation.

The moving nightly release is rebuilt daily when main has changed, and its Haxelib package keeps the version in haxelib.json. Versioned releases follow the WebGPU IDL snapshot pinned by xgpu, and their package takes its version from the tag. Asset names carry no version, so the latest nightly is always https://github.com/rayzor-blade/hlwgpu/releases/download/nightly/hlwgpu.zip.

The Wasm archive is an integration package rather than a standalone JS library. xgpu.wasm is a position-independent side module that shares the program's memory and table. See the host contract for the runtime imports and supplied JavaScript modules.

More documentation

• Using hlwgpu
• Architecture
• Current status and remaining work
• HXSL to WGSL

xgpu owns the API model, WebIDL input, generator, and reusable wgpu backend. hlwgpu owns the HashLink ABI adapter, release packaging, and HXSL compiler. hlwindow is xwindow's adapter for HashLink and Ash: the window package, loaded as xwindow.hdll, or as the side module xwindow.wasm in a page.
